Specifications
Nominal Impedance: Single 4-ohm
BL: 11.6
Inputs: Single Coil
Subwoofer Frequency Range: 33 Hz - 500 Hz
Voice Coil Size: 2 in
Material: Pressed Wool / Paper
Sensitivity (1W / 1M): 86 dB
Motor Structure: 116 oz
Cutout Diameter: 9 1/8 (230.1mm)
Mounting Depth: 5.25 in
Xmax: 9 mm
Spl: 86.6 dB
No: 0.29%
Qts: 0.4
Qes: 0.43
Qms: 5.12
Mms: 94.2 g
Cms: 270 uM/N
Vas: 43.8 Ltr
SD: 330.06 sqCM
Fs: 33.5 Hz
Test Impedance: 3.2-ohms
VC Impedance: 4-ohm
Size: 10 in
Sensitivity: 86 dB
Frequency Response: 33 Hz - 500 Hz
Voice Coil Size: 2 in
Power Handling (RMS/Peak): 275 / 550 watts
